Pompkettingen

Pump Chains, stainless

cromox pompkettingen CPK, Grade 60

gelast, getest, gestraald

cromox Pump Chains CPK, Grade 60

welded, tested, blasted

Type

Werklast

Topschalm

Ketting

Verbindingsschalm Euro

Euro per extram

Type

W.L.L.

Master link

Chain

Joining link

stuk/

pc

Verlengstuk

each add. m

t

mm

mm

mm

L1

Extension L2 = ca.1m

Afwijkende uitvoeringen op aanvraag

Custom fittings and fabrications available

Standaard lengte ≈ 1000 mm, andere lengtes op aanvraag

Standard Length ≈ 1000 mm; other lengths by request

L 1 = ca. 1m + een extra topschalm

L 1 = approximately 1m + one additional master link

L 3 = 2-spronguitvoering met harpsluiting

2-leg Extension with shackle

Afb.: Speciale uitvoering

Fig.: Customized edition

Verbindingsschalm

Connecting link

L 1 = Basisdeel

Basis component

L 2 = verlengstuk

Extension

= ca. 1m

Topschalm

Master link

CPK 3

CPK 4

CPK 5

CPK 6

CPK 7

CPK 8

CPK 9

CPK 10

CPK 13

CPK 16 (G5)

CPK 18 (G5)

0,20

0,40

0,63

0,90

1,25

1,55

2,00

2,45

3,85

5,00

7,00

5 x  42 x  22

8 x 54 x 30

10 x 80 x 50

13 x 110 x 60

13 x 110 x 60

13 x 110 x 60

16 x 110 x 60

16 x 110 x 60

22 x 160 x 90

22 x 160 x 90

26 x 180 x 100

3 x 14

4 x 16

5 x 15

6 x 18

7 x 21

8 x 24

9 x 27

10 x 30

13 x 39

16 x 48

18 x 54

5 x 22 x 9

6 x 26 x 13

8 x 35 x 19

8 x 35 x 19

10 x 44 x 25

10 x 44 x 25

13 x 54 x 25

16 x 70 x 34

18 x 85 x 40

22 x 115 x 50

25,30

33,20

41,20

53,00

58,00

65,00

79,00

93,00

152,00

212,00

310,00

13,00

22,40

28,90

37,80

41,90

49,90

61,30

76,50

121,50

179,00

278,00

!

Bestelinformatie/

Note:

Verschillende maten ook in Duplex te leveren!

Many sizes also available in Duplex!
